AM26LV32IDR Quad Differential Receiver 3V to 3.6V Operation 32Mbps ±15kV ESD Fail-Safe 8kV HBM Industrial Temp TTL/CMOS for RS-422/485 Networks

AM26LV32IDR Quad Differential Receiver 3V to 3.6V Operation 32Mbps ±15kV ESD Fail-Safe 8kV HBM Industrial Temp TTL/CMOS for RS-422/485 Networks

Features

• Switching rates up to 32 MHz

• Operates from single 3.3-V supply

• Ultra-low power dissipation: 27 mW typical

• Open-circuit, short-circuit, and terminated fail-safe

• −0.3-V to 5.5-V Common-mode range with ±200-mV sensitivity

• Accepts 5-V logic inputs with 3.3-V VCC

• Input hysteresis: 50 mV typical

• 235 mW With four receivers at 32 MHz

• Pin-to-pin compatible with AM26C32 and AM26LS32

Applications

• High-reliability automotive applications

• Factory automation

• ATM and cash counters

• Smart grid

• AC and servo motor drives

Description

The AM26LV32 device is a BiCMOS, quadruple differential line receiver with 3-state outputs, which is designed to be similar to the TIA/EIA-422-B and ITU Recommendation V.11 receivers with reduced common-mode voltage range due to reduced supply voltage.

The device is optimized for balanced bus transmission at switching rates up to 32 MHz. The enable function is common to all four receivers and offers a choice of active-high or active-low inputs. The 3-state outputs permit connection directly to a bus-organized system. Each device features high input impedance, input hysteresis for increased noise immunity, and input sensitivity of ±200 mV over a common-mode input voltage range from −0.3 V to 5.5 V. When the inputs are open-circuit, the outputs are in the high logic state.

The AM26LV32C is characterized for operation from 0°C to 70°C. The AM26LV32I is characterized for operation from −40°C to 85°C.

INFORMATION

Drawing

Our advantage :

• High quality products --- our offers are 100% new and original, ROHS
• Competitive price --- good Purchase channels with good price.
• Professional service --- strict quality testing before the shipment, and perfect after-sales service after the purchase.
• Adequate inventory --- With the support of our strong Purchasing team,
• Fast delivery --- we will ship the goods within 1-3 working days after the payment confirmed.

be sure to meet your need for all kinds of components. ^_^
